CE BS EN 12101-8 Certified
The FumaCE is tested to BS EN 1366-10 and certified to BS EN 12101-8. It is supplied on site pre-hung, ready to install. Simply fit in the opening and link to the smoke control system.
Download DoP
Discreet
Smoke Control
Damper
FumaCE | Smoke Control Damper
- 1000Pa Air Leakage
- 10k Cycle Tested
- BS EN 12101-8
- BS EN 1366-10
- CE Certified
- E120 Fire Rated
FumaCE
A concealed single blade smoke control corridor damper CE marked to BS EN12101-8:2011
FumaCE is a discreet passive fire protection product used in smoke shafts used to prevent the spread of smoke in high-residential or commercial offices.
FumaCE Smoke Control Damper
FumaCE is fully concealed smoke control damper that matches minimalist aesthetics, seamless functionality and offers 120 minutes fire integrity and insulation (EI 120).
FumaCE Advantages
FumaCE is a minimalist smoke control damper, designed to prevent the spread of smoke passing through multiple floors. Supplied fully hung, as an integral unit with a metal door, FumaCE is a lightweight damper and simply needs to be fitted into the opening and linked to the BMS (Building Management System).
Concealed frame Won't distract from your interior design
Most automatic ventilation systems and smoke control dampers on the market are unsightly and detract from a minimalist interior. The FumaCE can be concealed and is powder coated RAL 9010 as standard but other colours may be available. Contact sales@selo.global for more information.
Coaxial Spindle Drive Innovative safety technology
FumaCE use two high-torque, maintenance free spindle drives, cycle-tested to 10k cycles. Once installed, and linked into the buildings management system, the actuator is maintenance-free and only requires periodic testing with associated fire safety equipment.
E120 Fire-rated Butt Hinges Practical performance
Durable and maintenance-free hinges are used to provide smooth operation for the life of the product. Backed by a 25-year guarantee.
Quench® Fire-stopping system Fire protection buit-in
FumaCE now has the option to arrive on-site with the fire-stopping material pre-built into the frame for a faster, safer installation; removing potential fall risk and hazardous working environments. It also assists in mitigating risk from an installation perspective, giving assurance for both contractors and building control.
View Quench
Market-leading durability and reliability Exceptional performance without compromising on aesthetics
Fuma CE has been cycle tested to 10,000 open and close cycles to offer unmatched durability to couple the sleek minimalist design. The FumaCE smoke control damper also offers exceptional performance with air leakage requirement tested to 1000 Pascals (S1000) and automatic activation (AA) which has been factory tested.
The FumaCE smoke control damper is side-hung and opens inward using dual 24-volt linear actuators. It is typically controlled by a permanent power supply and two normally open interface relays to return open and closed signals. The FumaCE is designed to be installed in vertical smoke shafts, where it helps to control and extract smoke from hallways and corridors during a fire.
FumaCE is typically positioned in the hallways and corridors of buildings, such as high-rise residential or commercial office buildings, where it is installed along with other services.
FumaCE is manufactured from CR4 Mild Steel, and the material cannot be changed due to its CE rating requirements
CE marking is a symbol that manufacturers affix to products, such as smoke control dampers, to indicate conformity with applicable European standards and directives.
The advantages include: concealed design, high performance and certification, pre-hung, high quality and safety features. These features make FumaCE a robust, reliable, and user-friendly option for smoke control in buildings.
Yes, FumaCE is a concealed smoke damper. It is described as a “concealed, CE-certified smoke damper” It won’t distract from your interior design.
Yes, massively. As when doing the testing on a monthly basis you can power open all the units and if you can’t automatically close them, you have to go round closing each and every one which can be problematic.
You can obtain the specifications for the FumaCE system by contacting the Selo team, or NBS source. These resources should provide you with comprehensive specifications and additional details for the FumaCE riser door system.
You can download CAD Drawing here or by contacting the sales team at Selo. You can reach them by calling 020 3880 0339 or emailing sales@selo-uk.com.
FumaCE comes in two standard sizes:
- 0.6m² geometric area, with a damper height of 925mm and width of 760mm. The required structural opening is 1058mm high by 865mm wide.
- 1.0m² geometric area, with a damper height of 1275mm and width of 900mm. The required structural opening is 1408mm high by 1005mm wide.
No, it is recommended that ventilation shafts are kept separate to smoke extract shafts, because smoke extract is life safety, ventilation isn’t and very few products are suitable for use on both.
It has a fire rating of EI 120, meaning it provides 120 minutes of integrity and insulation. It is also classified to EN 13501-4 and has passed relevant fire resistance tests such as E (integrity), I (insulation), and S (smoke leakage) for EIS120 under EN 12101-8:2011.
Yes, the FumaCE smoke control damper has a pre-intumescent called Quench already installed in the frame, so it does not require mastic around the frame after installation.
Fuma CE has been cycle tested to 10,000 open and close cycles to offer unmatched durability to couple the sleek minimalist design.
